Products are widely used in various industrial marker, industrial laser modules, and instrument equipment, teaching test light source, laser medical equipment, stage lighting and demonstrate with a laser light source, laser positioning device, etc.
ESPECIFICACIONES:
Wave length: 405nm
Exit pupil power: 5mW~150mW (Choice)
Divergence angle: 0.1mrad ~ 0.6mrad
(eg. the 5mW in 1 meters width can be adjusted to the 0.5mm)
Fan angle: 30-90 degrees (Default 90)
Optics: optical glass lens
Working voltage: 6V, 7-15V optional
Threshold current: 40mA
Working current: 150mA
Laser level: …¡, III a, III: B
Working temperature: - 10 ℃ ~ 60 ℃
Storage temperature: - 40 ℃ ~ 80 ℃
Dimensions: Φ 16mm x 60mm
Modulación: TTL modulation
Modulation frequency: 1Hz-1000KHz
Working time: > 12 hours (good heat dissipation condition)
Wiring: Rojo line is (+), the black line is (-)
Garantía: 12 Months
TTL modulation Descripción:
1 The red and yellow lines shorted, the module will be lit, in a continuous mode of operation;
2 To modulate the signal line negative black wire, positive connected to the yellow line, red line vacant, modulation module in working condition.
3 Signal input modulation frequency must be within the range 500KHZ;
Warning :
1. All of laser products are harmful for eyes,please don't aim people eyes(contain animal eyes) directly.
2. It is Industrial laser ,not toy .Keep far from Children under 18years old.
