450nm 15W 105μm*5 Fibers Combining Module Azul Diode Fuente láser

450nm 15W 105μm*5 Fibers Combining Module Azul Diode Fuente láser

The fiber beam combining module is a multi-tube core combined beam semiconductor laser. Large contact area, low current package form, more stable performance, more convenient to use. The optical fiber parameters can be customized, and the built-in cooling chip will make the device performance more reliable and stable.

[Applications]
Laser night vision
Projection display
Laser Medical
Material testing

[Especificaciones]
nombre del producto: Láser de fibra acoplada
Longitud de onda: 450±5(nm)
Potencia de salida: 15W
Spectral Width: <3nm
Diámetro del núcleo de fibra: 400μm (105μm*5 Fibers Combining)
Numerical Aperture: 0.22
Fiber Connecter: FC/PC
Operating Current: 2.5~3.5A
Threshold Current: 0.4A
Tensión de funcionamiento: 12~16V
Power Conversion Efficiency: 35~50%
TEC (Semiconductor Refrigeration): 6A 12V
Operating Temperature: 10~35℃
Storage Temperature: -20~60℃
Operating Humidity: <60%
Lifetime: >10000 hours
