473nm 10mW~200mW blue fiber laser with power supply Support customized

New Pirce | Nuevo precio (Click Here | Haga clic aquí )

Por favor, elija:

Add to Cart | Añadir al carrito:

473nm 10mW~200mW blue fiber laser with power supply customize fiber diameter & length
Fiber-coupled laser features:
1. The length of fiber can be customized.
2. You can change the direction of the laser beam, it can be applied to a variety of occasions venue.
3. Laser spot is circular, uniform illumination.
4. The laser fiber can be installed at the exit of the collimator lens care area to adjust the size, large or small.
1. It's made-to-order products, we need 1~3 weeks to produce it.
2. The output power/fiber diameter/fiber length can be customized.
3. The marked output power is before coupling, coupling efficiency is about 80%~90%.
nombre del producto: 473nm fiber coupled laser with Power Supply
Product Include: Laser system with fiber + Controller + Power source
 Longitud de onda de salida: 473nm±2nm
Potencia de salida: 10mW~200mW(Escoger)
Operating Mode: CW or Modulation
Power Stability:  <±5% per 2 hrs
Estabilizador de temperatura: TEC
Tiempo de calentamiento: <5 minutes
Optimum Operating Temperature: 20~30℃
Storage Temperature: 10~50℃
MTTF(mean time to failure): 10,000 hrs
Fiber Type: Multi-mode fiber/MM fiber
Diámetro del núcleo de fibra: 105μm/200μm/400μm/600μm/800μm/1000μm (Escoger)
Apertura numérica de fibra: 0.22NA(100μm~400μm)/0.37NA(600μm~1000μm)
Fiber Interface(Output): FC/PC, FC/APC, SMA905 (Escoger)
Longitud de la fibra: 1m/2m/3m (Escoger)
Dimensión del cabezal láser: Near 100(L)*40(W)*50(H)mm3 (fan adds 15mm height) (Haga clic aquí para encontrar detalles)
Fuente de alimentación: Standard type power supply / Lab Adjustable power supply (Escoger)
Fuente de alimentación 1:Standard Power Supply (Escoger) (Haga clic aquí para encontrar detalles)
Fuente de alimentación 2: Lab Adjustable Power Supply (Escoger) (Haga clic aquí para encontrar detalles)
Modulación: 0~30kHz Analog or TTL
Garantía: 1 Year
Thermal printing
Material Inspection
Scanning Biochemistry
[Package include]
1 x 473nm fiber laser
1 x Laser power supply
