1570nm 5000mW Modo singular Fiber Fuente láser Potencia de salida ajustable

New Pirce | Nuevo precio (Click Here | Haga clic aquí )

Por favor, elija:



Add to Cart | Añadir al carrito:


1570nm 5000mW Modo singular Fiber Fuente láser Potencia de salida ajustable

The 1570nm single-wavelength laser uses a high-performance butterfly semiconductor laser chip, professionally designed drive circuit and TEC control to ensure the safe operation of the laser, stable output power and spectrum. It is suitable as a pump laser source for thulium-doped fiber lasers or fiber amplifiers.

[Features]
Modo singular fiber output.
Multiple spectra optional.

[Applications]
Thulium-doped fiber laser
Fiber optic sensing
Fiber laser

[Specification]

Parameter Unit Typical Value Remarks
Wavelength nm 1570±1nm 1565/1570nm customizable
Spectral Linewidth nm <0.1
Sideband Suppression Ratio dB >50
Output Power W 5
dBm 37
Short-term Stability (15 minutes) dB ≤ ±0.02
Long-term Stability (8 hours) dB ≤ ±0.05
Pigtail Type   SMF-28e single mode Personalizable
Pigtail Connector Type   FC/APC



Electrical and Environmental Parameters

Desktop Type

Control Method

Button

Communication Interface

DB9 Female
(Default not include)

Power Supply

100~240V AC, <150W

Size

260(W)×320(D)×120(H)mm

Operating Temperature Range

-5~+55°C

Operating Humidity Range

0~70%




1570nm sm Fiber laser

1570nm sm Fiber laser
