GBV 532nm/445nm/405nm Multi Wavelength Láser de fibra acoplada

GBV 532nm/445nm/405nm Multi Wavelength Láser de fibra acoplada

[Especificaciones]
nombre del producto: GBV fiber coupled laser
Longitud de onda: Verde:532nm, Azul:445nm, Violet: 405nm
Spatial Mode: Multimode
Potencia de salida: 532nm 2W / 445nm 4W / 405nm 0.6W
Operation Mode: CW or Modulation
Power Stability: <3% per 4 hrs
Tiempo de calentamiento: <1 minute
MTTF: 10,000 hrs
Fiber Type: Multi-mode fiber/MM fiber
Diámetro del núcleo de fibra: 100μm/200μm/400μm/600μm/800μm/1000μm (Escoger)
Apertura numérica de fibra: 0.22NA(100μm~400μm)/0.37NA(600μm~1000μm)
Fiber Interface(Output): FC/PC, FC/APC, SMA905 (Escoger)
Longitud de la fibra: 1m/2m/3m (Escoger)
Dimensión del cabezal láser: Near 185(L)x128(W)x50.5(H)mm3 (Haga clic aquí para encontrar detalles)
Fuente de alimentación: Lab Adjustable Power Supply (Haga clic aquí para encontrar detalles)
Laser Radiator/Heat Sink: Not Include/Include (Escoger) (Haga clic aquí para encontrar detalles)
Modulación: 0~30kHz Analog or TTL
Garantía: 1 Year

[Package include]
1 x GBV Fiber coupled  Laser
1 x Laser power supply
1 x Fiber

Nota:
1. The picture is for reference only, different outpower laser product, with different product size.
    If customer is concerned about the product size, please contact us before purchasing.

2. The marked output power is before coupling, coupling efficiency is about 80%~90%.
    For example, the 3W laser's actual output power of fiber coupled laser is >2.4W.
