808nm 200mw IR laser diode PD sales TO-18 5.6mm

808nm 200mw IR laser diode PD sales  TO-18 5.6mm

[Especificaciones]
Place of production: Japan
Longitud de onda de salida: 808nm
Potencia de salida: CW 200mW
Operating Current: <200mA
Tensión de funcionamiento: 1.8-2.2V
Package Type: T018(5.6mm)
Working life: >10,000 hours

[Note]
This component sensitive to static electricity, anti-static measures do not make direct contact with the laser tube by human hand, in addition to the product must have a qualified driver circuit before work, different laser beam power with the same working voltage, but  operating current is different, the circuit of the tube drive current needed to control in a safe range, otherwise it will affect life expectancy.
