685nm 1~800mW CW Laser System All-in-one Mode Rojo Laser Beam

New Pirce | Nuevo precio (Click Here | Haga clic aquí )

Por favor, elija:







Add to Cart | Añadir al carrito:


685nm 1~800mW CW Laser System All-in-one Mode Rojo Laser Beam

[Features]
1. All-in-one integrated machine: laser and power together, not separated.
2. Personalizable software control. (Default without. Add $ 150 for software control.)

[Especificaciones]
nombre del producto 685nm Láser de fibra acoplada
Tiempo de espera: 2~4 weeks
Longitud de onda: 685±5 nm
Potencia de salida: 800mW (@ Fiber output side, and 0~max power adjustable)
Spectral Linewidth:<2nm
Diámetro del núcleo de fibra:  200μm / 400μm (Escoger)
Fiber Interface: FC/PC, SMA905 (Escoger)
Control Mode: Button / Button+software (Escoger)
Longitud de la fibra: 1m
Apertura numérica de fibra:0.22NA
Operating Temperature: 0°C-40°C
Storage Temperature: -40°C-85°C
Estabilizador de temperatura: TEC
Tiempo de calentamiento: <5 minutes
MTTF(mean time to failure): 10,000 hrs
Dimensión del cabezal láser: Near 268(L)x160(W)x82(H)mm
Fuente de alimentación: Adjustable Power Supply
Modulación: 0~10KHz TTL
Garantía: 1 Year

[Packing List]
1 x All-in-one laser
1 x Optical fiber
1 x Test data report
1 x Operation manual



fiber coupled laser

fiber coupled laser

fiber coupled laser

fiber coupled laser

fiber coupled laser

fiber coupled laser


Installation size (forward installation, install the adapter plate at the bottom of the power supply)

fiber coupled laser


Installation size (reverse installation)

fiber coupled laser
