730nm 2W~3W Láser de fibra acopladaHigh Performance Sistema de láser IR
This product is for multimode fiber coupling of semiconductor laser,the stability of the output power of the fiber is good and the spot pattern can be improved to a great extent.The collimated beam can meet the high requirement of the beam.
Our company produces single wavelength, polarization maintaining and multimode fiber coupled lasers at various wavelengths, as well as fiber optic coupled lasers with fiber coupled lasers.Please contact us.
Notes:
This is a custom product. If you need other output powe or have special requirements, please contact us.
Tiempo de espera: 2~4 week! Custom product available!
[Features]
1.High power stability(<3%)
2.Multimode fiber coupled,fiber output.
[Especificaciones]
Longitud de onda: 730nm±5nm
Potencia de salida: 2W~3W(choose) (@ Fiber output side, and 0~max power adjustable)
Operating Temperature: 0°C-40°C
Storage Temperature: -40°C-85°C
Modulación: 0~10KHz TTL
| Parameter |
Work condition |
Symbol |
Min. |
Typical Value |
Max. |
Unit |
| Output Power |
@PO |
PO |
|
|
2000~3000(choose) |
mW |
| Power Stability |
2hrs |
Ps |
|
|
3 |
% |
| Central Wavelength |
@PO |
λc |
|
730 |
|
nm |
| Spectral linewidth |
@PO |
FWHM |
|
2 |
|
nm |
| Fiber core diameter |
|
Default 400um/NA=0.22(600um can be Customized) |
| Fiber Length |
|
|
|
100 |
|
cm |
| Fiber Type |
MM Fiber |
| Fiber interface |
|
|
FC/PC、FC/APC、SMA905 (choose) |
|
| Warming Time |
@PO |
Tw |
|
|
5 |
min |
| Noise |
RMS(10Hz-100MHz) |
N |
|
1 |
|
% |
| Service Life |
@PO |
MTBF |
10000 |
|
|
Hrs |
